4'' stroke 110 pound linear drives electric 12volt dc, remote controller linear actuator with mounting bracket

Specification of Electric Linear Actuator:

Features & Benefits of electric linear actuator

• Limit Switches - internal, factory preset
• Zinc Die Cast Housing for strength
• Aluminum outer tube for corrosion resistance
• Keyed translating tube to prevent rotation
• Polished aluminum translating tube for smooth operation
• Warranty - 1 year, parts and labor

Options of linear actuator
■ Potentiometer,
■ Signal sending limit switch
■ Stainless steel translating tube
■ Custom cable lengths
■ Wired or wireless handsets
■ DC power supply for multiple actuators
■ Stepper motor
■ Custom design models




Outline drawing of Electric Linear Actuator

Electric Linear Actuator Without Pot


Electric Linear Actuator With Pot

How do I select linear actuators?

There are many factors to consider when selecting a linear actuator for an application need.
Some of these important parameters are mentioned below:

• Stroke length (travel length)
• Installation length
• Mounting requirements
• Feedback
• Motor voltage
• Dynamic load
• Static load
• Speed

Some examples of applications where LINEAR ACTUATOR / ELECTRIC CYLINDER are in use:

• Locking mechanisms for vehicle-mounted wheelchair lifts
• Moving device for Patient lifter
• Driving the movement in robotic hands
• Used for testing touch screens on mobile devices
• Titling the boom/brush of Vehicles
• Car window opener
• Open/Close the valve
• hoist-style lift for scooters and powerchairs

We will help you choose the best actuator for your application.
From your first prototype right through to full-scale production of your product, we will be there to support you.
